Product Description:

The single-stage reverse osmosis system is an effective water treatment equipment that uses reverse osmosis membrane technology to eliminate dissolved ions and pollutants in water by applying pressure to make water molecules pass through the semi-permeable membrane. This technology is capable of reducing total dissolved solids (TDS), heavy metals and other harmful substances in water, providing high-quality pure water, and is widely used in food and beverage, pharmaceutical, and other industries.

Working Principle:

The single-stage reverse osmosis system operates based on the selective permeability of the reverse osmosis membrane. When the raw water is pressurized by a high-pressure pump, the water molecules are forced to pass through the reverse osmosis membrane while most of the dissolved ions, bacteria, and organic matter are blocked on the other side of the membrane, thereby achieving water purification. The reverse osmosis membrane has small pores, allowing only water molecules to pass through while retaining larger solutes, resulting in two types of water quality – purified pure water and concentrated water.

Working Steps:

The working steps for the single-stage reverse osmosis system include raw water-pretreatment-security filter-high-pressure pump-RO.

Features:

The product has several functions:

1. Removal of dissolved solids: The product effectively removes salt, heavy metals, and other dissolved solids in water.
2. Microbial control: The product removes bacteria, viruses, and other microorganisms in water to ensure the water quality's safety.
3. Water quality improvement: The product improves the conductivity and cleanliness of water to meet industrial use standards and drinking standards.
4. Wastewater reuse: The product is suitable for the treatment and reuse of industrial wastewater to reduce water resource waste.

The product has several features:

• High efficiency: The product has an excellent desalination rate and water purification capacity, allowing it to handle various water sources.
• Skid structure: The product's structure can be flexibly configured according to water demand, making it convenient for expansion and maintenance.
• Advanced control system: The product is equipped with intelligent monitoring and automatic control, allowing for real-time monitoring of water quality and system operation status.
• Energy-saving design: The product's system design is scientific and reasonable, with low energy consumption and low operating costs.
• Stable water output: The product continuously provides stable, high-quality water output to meet various industrial needs.

Technical Parameters:

The maximum operating temperature for the system is 45℃. This means that the system cannot be exposed to temperatures that are beyond this temperature limit as it may cause damage to the system. Additionally, the maximum operating pressure for the system is 41bar while the maximum pressure drop is 1bar. It is important to ensure that these pressure limits are not exceeded during the operation of the system as it may cause problems in the system.

The system has different pH value ranges depending on whether it is in continuous operation or short-term cleaning. For continuous operation, the pH value range is from 2 to 11. However, for short-term cleaning, the pH value range is extended from 1 to 13. It is essential to ensure that the pH levels are maintained within these ranges as it may affect the system's efficiency and operation.

The maximum water flow rate for the system depends on the specific model. For the 4040 model, the maximum water flow rate is 3.6t/h, while for the 8040 model, the maximum water flow rate is higher at 19t/h. The maximum water supply SDI is 5. This means that the system should not be exposed to water that has an SDI higher than 5 as it may cause damage to the system.

The allowable free chlorine content for the system is 0.1ppm. It is important to ensure that the free chlorine content in the water supplied to the system does not exceed this limit as it may cause damage to the system.

Applications:

Water treatment systems have various applications in different industries to provide high-quality water for specific purposes. The primary application areas of such systems include:

• Desalination of seawater and brackish water
• Chemical industry: used for chemical reaction and cooling circulating water treatment to ensure the stability of the production process
• Electronic industry: used for the preparation of industrial pure water and electronic grade high-purity water to ensure the cleanliness of the production environment
• Food and beverage industry: purify production water to meet food safety standards
• Pharmaceutical industry: provide high-purity water that meets the requirements of drug production to ensure product quality
• Environmental protection industry: sewage reuse treatment and special separation to help enterprises reuse and save resources

System Design:

The design of a water treatment system typically includes the following components:

1. Raw water tank (liquid level) design
2. Raw water pump design
3. Pretreatment design
4. Reverse osmosis design
5. Production water tank design

Support and Services:

Our Industrial Reverse Osmosis Systems are designed to provide high-quality purified water for various industrial applications. Our systems are equipped with advanced technologies that enable efficient removal of impurities, contaminants, and minerals from feed water, resulting in pure and high-quality water that meets the required standards.

We offer comprehensive technical support and services to ensure the optimal performance of our Industrial Reverse Osmosis Systems. Our team of experienced engineers and technicians can provide installation, maintenance, and repair services for our systems to ensure that they operate smoothly and efficiently.

In addition, we also offer customized solutions to meet specific industrial water treatment requirements. Our experts can work with you to design and develop tailored systems to meet your unique needs and specifications. We also provide training programs to educate your staff on the proper operation and maintenance of our systems.
